Second Hand Pile Driver Good Quality Long Lasting Use

Brand Name : VIBRA

Model Number : FV-400

Place of Origin : SHANGHAI

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, D/P, Western Union, MoneyGram

Supply Ability : 10 set/month

Delivery Time : 7-35 days

Packaging Details : 7.616 CBM

Name : Hydraulic Sheet Pile Driver

Feature : Easy Maintenance

Operation Pressure : 32 Mpa

Arm : 750 kg

Hammer : 2700 kg

Vibration Frequency : 3200 rpm

Excavator : 45-60 Ton

Max. Pile Length : 18 m

Centrifugal Force : 485 Kn

Contact Now

Low Noise Hydraulic Pile Driver Applied To Various Working Environments

Description

Hydraulic Pile Drivers are featured with no noise, no vibration, no pollution and no rubbish left in construction site.It can work with H-piles, precast concrete and steel piles with different shapes,like round,square and tapered shape.

Second Hand Pile Driver Good Quality Long Lasting Use

Features

  • Pile driving steel sheet pile, cement pile, steel rail pile, iron plate, H steel
  • Quick converting operation; Applied to various working environments.
  • Compared to other systems , less force required for pile pulling
  • Not damage the top or bottom of steel pipe pile, steel plate pile and steel rail pile.
  • Not damage the building even often work near it.
  • Adopted Rubber sheath to reduce noise and vibration, the operation is quiet and the working period is short;It is helpful to overcome environmental problems.
  • According to the placement direction of sheet pile and site conditions, the sheet pile can be clamped or lowered by positive and negative rotation of 180 °. The vibration frequency can be adjusted by two levels, and the two-level double pumps are combined to greatly increase the excitation force.
  • Second Hand Pile Driver Good Quality Long Lasting Use

Technical Parameter

Item FV-250 FV-280 FV-300 FV-330 FV-350L FV-350 FV-400
Vibration Frequency (rpm) 2500 2800 3200 3200 3200 3200 3200
Operation Pressure (Mpa) 30 32 32 32 32 32 32
Centrifugal Force (KN) 265 335 350 372 435 455 485
Max.Pile Length (m) 10 12 12 12 15 15 18
Arm (kg) 500 500 670 670 670 750 750
Hammer (kg) 1700 1900 2100 2300 2400 2600 2700
Excavator (T) 20-30 20-30 30-35 33-40 35-40 40-45 45-60

About Us

Shanghai Yekun Construction Machinery Co., Ltd. was founded in 2014. A professional company involving in hydraulic vibrating pile driver manufacture, sale and service. Our company take the latest high speed hydraulic vibrating pile driver and its components as the main products. Our products vastly apply for infrastructure & construction industries.

We focus on product quality with the latest industrial technology. The mini hydraulic vibrating pile driver lead the industrial trend. The middle and large hydraulic vibrating pile driver also are highly recognized by our clients. At the same time, we actively cooperated with the engineering machinery factory and construction company to jointly develop more functional professional equipment, and we hired foreign professionals as our technical adviser.

Second Hand Pile Driver Good Quality Long Lasting Use

Second Hand Pile Driver Good Quality Long Lasting Use
